Power Over Ethernet Surge Protector DT-CAT 6A/EA

DIN rail installation, for PoE with nominal currents up to 1 A, enables equipotential bonding, terminal protection via separate device.

Support for Power over Ethernet + up to 1A (PoE+ according to IEEE 802.3at)

CAT 6A in the channel according to ANSI/TIA/EIA-568

For installation in conformity with the lightning protection zone concept at the boundaries from 0_B-2 and higher

Main Specification

Model No.	DT-CAT 6A/EA
	SPD according to IEC/EN 61643-21	Class II / Type 2
	Maximum continuous operating voltage (AC) U_c	41V
	Maximum continuous operating voltage (DC) U_c	58V
	Maximum continuous operating voltage (DC) Pair-Pair (PoE) U_c	57V
	Rated current I_L	1A
	Impulse durability (Line - Line)	C1: 500V / 250A
	Nominal discharge current C2 (Total)	7kA
	Impulse durability (Line - PE)	C2: 5kV / 2.5kA
	Impulse durability (Line - PE)	C3: 1000V / 10A
	Impulse durability (Line - PE)	C1: 1000V / 500A
	Total discharge current (10/350)	2.5kA
	Protection level U_p C1 (Line - Line)	500V
Protection level U_p C2 (Line - Earth)	600V
Protection level U_p C3 (Line - Earth)	600V
Enclosure material	Aluminum housing
Earthing via	Connecting line
