PCB Mounting Surge Protector SLP20P-275

For PCB mounting

Fast Response

Compact Design

Protective Elements: High Energy MOV

Compliance: IEC 61643-11:2011, EN 61643-11:2012

Specification

Model No.	SLP20P-275
	Nominal Voltage U_n	230V
	Max. Continuous Operating Voltage U_c	275V
	Type	Type 2 / Class II / Class C
	Nominal Discharge Current (8/20 μs) I_n	10kA
	Maximum Discharge Current (8/20 μs) I_max	20kA
	Voltage Protection Level U_p	1200V
	Response Time	< 25ns
