Type 1+2 AC Surge Protective Device FLP7-275/4S

TUV, CB, and CE certifications

Three Phase

High discharge capacity due to heavy-duty zinc oxide varistor

Location of Use: Main Distribution Boards

Network Systems: TN-S

Mode of Protection: L-PE, N-PE

Housing: Pluggable Design

Compliance: IEC 61643-11:2011, EN 61643-11:2012

Specification

Nominal voltage U_n	230V
	Max. continuous operating voltage U_c	275V
	Type	Type 1+2 / Class I+II / Class B+C
	Impulse discharge current (10/350 μs) I_imp	7kA @ Type 1
	Nominal discharge current (8/20 μs) I_n	20kA @ Type 2
	Maximum discharge current (8/20 μs) I_max	50kA @ Type 2
	Protective elements	Metal Oxide Varistor (MOV)
