Type 1 AC Surge Protective Device FLP25-275/3S

Adapting heavy-duty zinc oxide varistor

Adopting two stacked MOVs

Adopting wider dual-claw contacts

Location of Use: Main Distribution Boards

Network Systems: TN-C

Mode of Protection: L-PEN

Housing: Monobloc Design

Compliance: IEC 61643-11:2011, EN 61643-11:2012

Specification

Nominal voltage U_n	230V
	Max. continuous operating voltage U_c	275V
	Type	Type 1 Class I / Class B
	Impulse discharge current (10/350 μs) I_imp	25kA @ Type 1
	Nominal discharge current (8/20 μs) I_n	25kA @ Type 2
	Maximum discharge current (8/20 μs) I_max	100kA @ Type 2
	Protective elements:	Metal Oxide Varistor (MOV)
